DisplayCAL with Apple M1 and external monitor

Who by means of DisplayCAL and a colorimeter like a datacolor Spyder 5 If you want to calibrate an external monitor on a Mac with Apple M1 (Pro & Max are also affected), you will quickly run into the problem that DisplayCAL does not recognize the external display. The solution for this is simple.

DisplayCal uses the Argyll Color Management System, short ArgyllCMS. However, DisplayCal comes with an older version of ArgyllCMS that is simply not yet able to recognize the external devices on the M1. With the current ArgyllCMS version (2.3.0 at the time of this writing) the problem is solved and DisplayCAL can be used.

Getting DisplayCAL to use the newer ArgyllCMS version is quite easy:

  1. Download DisplayCAL and install
  2. The current Download ArgyllCMS version and unpack
  3. In DisplayCAL the path to the ArgyllCMS executables can be selected, there select the new ArgyllCMS version
  4. The external display should be recognized normally and the calibration can be performed.
Screenshot 2022 02 06 at 11.51.33
DisplayCAL selection of ArgyllCMS executables

After successful calibration, the color profile is available for selection and can be used:

Screenshot 2022 02 12 at 13.45.55

In some posts about this solution there was problem with the execution rights for the ArgyllCMS executables, this problem did not exist in my case. If there is a corresponding error message, the files must be provided with appropriate rights one by one.

Last updated on February 29, 2024 at 12:03 . Please note that the prices displayed here may have changed in the meantime. All information without guarantee.
Last updated on February 29, 2024 at 12:13 . Please note that the prices displayed here may have changed in the meantime. All information without guarantee.

2 comments

  1. Do you make it work for the mode LCD White LED?
    because for Generic mode works, but most of the monitors need the mode LCD White LED

  2. For me, it works also with the "LCD White LED" mode - does it produce any errors on your system?
